Digital PID Temperature Controller SESTOS D1S-CR-24, AC/DC 12-24V, -50 to 1300℃, K Sensor, Relay Output Alarm
Digital PID Temperature Controller SESTOS D1S-CR-24
$42.99
Out of stock
Standard DIN 48x48mm Panel Mount Design：This smart digital thermostat features an industry-standard 48x48mm DIN size housing, ensuring easy installation and seamless integration into existing control panels and automation systems.
Universal Multi-Sensor Compatibility：Supports a wide variety of sensor inputs including K, S, Wre, T, E, J, B, N, CU50, and PT100, providing exceptional flexibility to meet diverse application requirements across different heating and cooling processes.
Wide Control Range & High Accuracy：Delivers precise temperature regulation from -50°C to 1300°C (with K-type sensor). Features an indication accuracy of 0.1°C and control accuracy of ±0.2% FS, ensuring stable and reliable thermal management.
Flexible PID & ON/OFF Control with Digital Filter：Offers both advanced PID control and straightforward ON/OFF control modes. An adjustable digital filter reduces external interference, allowing users to configure the controller for optimal performance in any environment.
Auto-Tuning & Parameter Lock Functions：Equipped with self-tuning technology to automatically optimize control parameters for enhanced efficiency. The parameter lock prevents unauthorized setting changes. Powered by a universal AC/DC 12-24V supply, featuring 4-20mA analog current output for precise actuator control and a dedicated relay alarm output for system protection.
The SESTOS D1S-CR-24 is an advanced digital PID temperature controller designed for precise industrial thermal regulation. Housed in a standard DIN 48x48mm panel mount enclosure, this controller combines high accuracy with versatile input/output options to meet demanding automation requirements.
This universal input thermostat is compatible with a comprehensive range of thermocouples (K, J, S, E, etc.) and RTDs (PT100, CU50), covering a broad temperature spectrum from -50°C to 1300°C. Users can select between PID control (with an adjustable digital filter to suppress noise) and simple ON/OFF control for maximum flexibility. The built-in auto-tuning function streamlines setup by automatically calculating optimal PID parameters, while the parameter lock safeguards your configuration.
A key differentiator of the D1S-CR-24 is its 4-20mA analog current output, ideal for interfacing with proportional valves, SCR power controllers, or variable speed drives. A separate relay alarm output provides independent fault indication or safety interlocking. Operating on a wide AC/DC 12-24V power supply, this controller is a robust solution for ovens, furnaces, extruders, packaging equipment, and HVAC systems.
